Rainscreen facades
Ventilated facade substructures
A metal frame of brackets, rails and clips that carries the cladding. The air gap keeps insulation dry, and installation is dry and possible all year round.
- Seismic
- 7, 8, 9 points
- Fire class
- K0
- Supply
- substructure + cladding
About the system
Seismic safety comes first in Armenia. GARM facade systems are approved for zones with design seismicity of 7, 8 and 9 points; bracket and rail spacing is defined by structural calculation for the specific building and cladding.
Claddings: porcelain stoneware, fibre cement, metal cassettes, ACP, siding, profiled sheet. Fire hazard class K0.
Facade and ceilings from one supplier mean one delivery, one invoice and one specification.
Facade price is calculated per project: it depends on cladding, bracket projection, building height and seismic zone.
Three substructure types
| Type | Composition | For |
|---|---|---|
| Cross | L- and U-profiles, brackets, clips | porcelain stoneware |
| Vertical | vertical T- or L-rails only | siding, profiled sheet, cassettes |
| Floor-to-floor | fixed into floor slabs | RC frame buildings with aerated-concrete infill |
Cladding options
FAQ
Are the systems suitable for Armenia’s seismic zones?
Yes, they are approved for 7, 8 and 9 point zones; fixing spacing is calculated per building.
Can you fix to aerated concrete walls?
Use the floor-to-floor system — it is fixed into the slabs, not the blocks.
Do you supply cladding too?
Yes, we supply the substructure and cladding together.
We will price your project
Send us the area or a drawing — we will prepare a bill of materials with a 5% allowance and a quote per m² and per project.
